TW-400 CUB™
Small, Rugged full-featured handheld TSM radio
The TW-400 CUB radio is a portable radio designed for voice communications and sensor networks.
Network Video Streaming
Capture video, view multiple video streams simultaneously, or forward video to others in your network with CUB’s on-board analog-to-digital video encoder. The H.264 encoder is interoperable with standard video players for different platforms. Consume video with an Android™ device and specialized software, such as TrellisWare’s TARC application.
Power Conserving Operations
Enhance your low-profile TSM network with CUB’s sleep modes for longer operation times. The Wake on Wireless and Wake on Trigger sleep modes are built to minimize power consumption with local triggers. While the CUB radio is covertly left as a relay, use the sensor dongle for full network awareness to detect activated video streams, motion, audio, or any network changes.
Connect Multiple IP Networks
Extend network range by cross-connecting multiple IP networks deployed. The CUB radio effortlessly bridges a TSM and an external IP network together with CUB’s built-in gateway feature. In this way, connect to a very small aperture terminal (VSAT) for a satellite network link that works as a backhaul to a wider enterprise network.
Sensor Dongle
Control all IP sensor traffic with CUB’s sensor dongle accessory. Conveniently collect information, surveillance, and reconnaissance (ISR) for any mission, and leave it unattended as a ground sensor for perimeter or motion detection. The sensor dongle features an Ethernet connector, analog video input, power output providing a constant 3.3 V power source, and power saving trigger inputs and outputs.
Android™ is a trademark of Google Inc.
PHOTO CREDITS: Soldier Overlook: U.S. Army Spc. Steven Cope
| Size | 4″ (H) x 2.5″ (W) x 0.9″ (D) |
| Weight (R/T only) | 10 oz |
| Frequency Range | 1775–1815 MHz, 2200–2250 MHz |
| Occupied Bandwidth | 20 MHz, Configurable to 4 MHz |
| Transmit Power | Up to 2 W |
| Input Power | 6–18 V DC with Power Adapter |
| Battery Life | 8 Hours with 32 Wh Rechargeable Battery |
| Environmental | MIL-STD-810G |
| Water Resistant | 2 M Immersion |
| Connectors | LEMO Audio, SMA RF and GPS Antennas, 24-pin for Dongles |
| Data Rate | 8 Mbps IP Throughput per Channel |
| Audio Encoding | AAC Audio, AMR 5.9 or MELPe, Up to 12 Channels |
| Audio Latency | 3 Hop < 275 ms, 8 Hop < 400 ms |
| Video Encoding | MJPEG or H.264 |
| Net Entry Time | < 1 Second |
| Waveform | TSM |
| Routing | Barrage Relay™ networking |
| Modulation | Constant Envelope |
CUB Applications Running with TSM
CUB is a rugged and reliable handheld radio, and like other TSM products, it is a receiver, transmitter, and relay all in one, running with robust TSM networking technology.
- Awareness of physical or environmental conditions with sensor technology
- Constant real-time intelligence
- Body worn, or use remotely with sensor access and control
- Robust mobility and connectivity in highly dynamic environments
- Operates with other TSM products
- Simultaneous voice, data, and PLI
