TW-870
TSM Ghost™
Fully Integrated Radio Module
The TW-870 TSM Ghost™ is the smallest form factor TSM radio without having to integrate at the board level.
Easy to Embed
The TW-870 provides the simplest integration path for platforms and assets that do not require the full feature set of a dismounted user radio. The radio covers the UHF, L-Band, and S-Band frequencies, and is very low profile in design.
Rapid Deployment
Deploying and integrating the TW-870 is achieved by connecting RF and GPS antennas, data and power. It is lightweight and ideal for unmanned systems or any fast deployed mobile ad-hoc networking scenarios.
| Size | 4.06″ (H) x 2.25″ (W) x 0.62″ (D) |
| Weight (R/T only) | 8.8 oz. |
| Frequency Range | L-UHF: 225–450 MHz U-UHF: 698–970 MHz, L/S Bands: 1250–2600 MHz |
| Configurable Bandwidth | 1.2, 4, 10, 20, 40 MHz |
| Transmit Power | 100 mW, 250 mW, 500 mW, 1 W, 2 W |
| Environmental | MIL-STD-810G |
| Operating Temperature Range | -20C to +55C |
| Water Resistant | IP68 |
| Connectors | USB On-the-Go, RF SMA, GPS SMA 4-pin ODU power |
| Power Input | 5 V to 20 V |
| Data Rate | Pt. to Pt., up to 16 Mbps (1 hop) |
| Waveform | TSM Release 6 |
- Flexible module for tactical communications platforms
- Ideal for unmanned systems
- Easy to embed and lightweight
- Simultaneous voice, data, and PLI
- Operates with other TSM products
