TW-950 TSM Shadow™
Wide Frequency Range, High Throughput Handheld
TrellisWare’s next generation radio featuring unparalleled performance powered by the TSM™ waveform.
Mission Flexibility
The TW-950 TSM Shadow provides an expanded frequency range, higher throughputs for streaming multiple High Definition (HD) videos, and is interoperable with devices that run TSM-X™ waveform functionality. The TW-950 TSM Shadow radio is redefining the edge of tactical networking.
- Up to 16 Mbps
- Up to 16 Voice Channels
- SD and HD H.264 Video Encoding
- UHF, L-band, S-band in a Single Radio
TW-650 TSM Shadow™ Module
TrellisWare’s single-board software-defined (SDR) radio is built for integration into custom platforms, drones, robotics and existing systems. This single radio module includes UHF, L-band, and S-band frequencies, and is low profile in design with optimal size, weight, and power. The TSM Shadow module has fully-compatible networking functionality with all current TrellisWare® radio products.
- Embedded Integration
- Extensive Feature Set
- TSM Waveform Release 6
- RF Spectrum Flexibility
- Interoperability
| Size | 4.54″ (H) x 2.76″ (W) x 0.90″ (D) |
| Weight (R/T only) | 11.3 oz |
| Frequency Range | 225–450 MHz, 698-970 MHz, 1250–2600 MHz |
| Occupied Bandwidth | 1.2, 4, 10, 20, 40 MHz |
| Transmit Power | Up to 2 W |
| Input Power | 6–18 V DC with Power Adapter |
| Environmental | MIL-STD-810G |
| Water Resistant | IP68 |
| Connectors | SMA GPS, ODU Data/Audio, TNC RF |
| Data Rate | 16 Mbps IP Throughput |
| Audio Encoding | AMR 5.9, MELPe, AAC Audio |
| Voice Channels | Up to 16 Channels |
| Video Encoding | Built-in H.264 video encoder, 1080p 30fps HD video |
| Net Entry Time | < 1 Second |
| Waveform | TSM Release 6 |
| Routing | Barrage Relay™ networking |
| Modulation | Constant Envelope |
TSM Shadow is built to to deliver TSM-X waveform capabilities for different tactical operations.
- Enhanced network throughput
- Multi-cast HD video
- Flexible bandwidth
- Adaptable capability
- Waveform portability
TrellisWare offers 24/7 support for technical issues and a resourceful online Customer Support Center. The Support Center includes current software updates, documentation, frequently asked questions, and information about TrellisWare University training classes.
Current users of TrellisWare® products and development partners may register to access the Support Center at: https://support.trellisware.com
