Waveforms
Groundbreaking TrellisWare® waveforms provide unparalleled resiliency in the most challenging
operational conditions, with massive scalability and unmatched spectrum efficiency.
Mobile Ad Hoc Networks (MANETs) have become the backbone of tactical communications due to their exceptional flexibility, security, and reliability. With the defense battlespace and commercial communications space constantly becoming more contested and congested, the need for reliable, secure, and scalable communications remains a top priority for communications decision makers.
Our expertise in waveform technology has been validated in real and critical missions with diverse use cases in some of the most challenging environments. TrellisWare's TSM® waveform is incorporated into a wide range of systems, including TrellisWare® radios, embeddable modules, trusted industry partner radios, as well as multiple government and commercial solutions. It is the interoperability standard in tactical MANET waveforms, offering unmatched reliability and 10X spectrum support over competing solutions.
The TSM® waveform (current version TSM 6.2.1) provides for enhanced network throughput, unicast and multicast HD video, flexible bandwidth, adaptability, and waveform portability. In highly mobile operations, TSM networking supports critical situations with true tactical agility.
TSM is a commercial, wireless, wideband MANET waveform software that operates on TrellisWare® radio products. The TrellisWare TSM Partner Platform Waveform Software operates on third-party radio products.
TSM Waveform
The TSM-X™ waveform is a version of the TSM® waveform that includes specifically designed software functions to support and interface to NSA-certified (Type-1) security architectures. TSM-X networking features enhanced network throughput, unicast and multicast HD video, flexible bandwidth, adaptability, and waveform portability.
The TSM-X waveform was chosen as the primary tactical MANET technology for the U.S. Special Operations (US-SOCOM) next-generation handheld and next-generation manpack radios. The waveform delivers robust, reliable, and scalable networking to 500+ nodes in a single RF channel, especially for tactical operations in challenging RF environments.
TSM-X with STC Security is the standard waveform for US-SOCOM MANET-capable radios. TSM-X with WREN Security offers interoperability between Army Program of Record (PoR) partner radios.
- Robust – immune to network volatility in highly dynamic networks
- Reliable – consistent throughput with voice and data services you can count on
- Scalable – to address small-to-large and complex networks
TrellisWare led the development of the Warrior Robust Enhanced Network Narrowband (WREN NB) waveform for the US Army. The WREN NB capability enables spectrum efficiency for tactical communications, and addresses challenges faced by current communications solutions.
The WREN NB waveform is a US Army Program of Record (PoR) waveform on multiple vendor platforms, and answers the battlefield needs of today and tomorrow. WREN NB has wide frequency coverage as well as massive scalability. It provides mitigation against intentional and unintentional electronic warfare threats. The waveform includes secure IP network capabilities, extended network range, and interoperability between different radio platforms. WREN NB provides a highly scalable and robust waveform with simplified network management for operations in congested or contested environments.
- PoR waveform on multiple vendor platforms
- Secure And Below (SAB) communications
Katana™: TrellisWare’s Next-Generation Waveform
Increasing resiliency for the modern battlefield with the modernization of long-range narrowband communications
- Designed to operate in highly contested radio frequency (RF) communication environments, the Katana waveform combines resilient narrowband fast frequency hopping with tactical MANET
- Facilitates communications in near-peer threat environments and provides broad spectrum allocation options for global deployment
- Interoperable with the WREN-NB waveform at the SBU security level
TSM™Release 6
The TSM® waveform (current version TSM 6.2.1) provides for enhanced network throughput, unicast and multicast HD video, flexible bandwidth, adaptability, and waveform portability. In highly mobile operations, TSM networking supports critical situations with true tactical agility.
TSM is a commercial, wireless, wideband MANET waveform software that operates on TrellisWare® radio products. The TrellisWare TSM Partner Platform Waveform Software operates on third-party radio products.
TSM Waveform
TSM X™
The TSM-X™ waveform is a version of the TSM® waveform that includes specifically designed software functions to support and interface to NSA-certified (Type-1) security architectures. TSM-X networking features enhanced network throughput, unicast and multicast HD video, flexible bandwidth, adaptability, and waveform portability.
The TSM-X waveform was chosen as the primary tactical MANET technology for the U.S. Special Operations (US-SOCOM) next-generation handheld and next-generation manpack radios. The waveform delivers robust, reliable, and scalable networking to 500+ nodes in a single RF channel, especially for tactical operations in challenging RF environments.
TSM-X with STC Security is the standard waveform for US-SOCOM MANET-capable radios. TSM-X with WREN Security offers interoperability between Army Program of Record (PoR) partner radios.
- Robust – immune to network volatility in highly dynamic networks
- Reliable – consistent throughput with voice and data services you can count on
- Scalable – to address small-to-large and complex networks
WREN NB Waveform
TrellisWare led the development of the Warrior Robust Enhanced Network Narrowband (WREN NB) waveform for the US Army. The WREN NB capability enables spectrum efficiency for tactical communications, and addresses challenges faced by current communications solutions.
The WREN NB waveform is a US Army Program of Record (PoR) waveform on multiple vendor platforms, and answers the battlefield needs of today and tomorrow. WREN NB has wide frequency coverage as well as massive scalability. It provides mitigation against intentional and unintentional electronic warfare threats. The waveform includes secure IP network capabilities, extended network range, and interoperability between different radio platforms. WREN NB provides a highly scalable and robust waveform with simplified network management for operations in congested or contested environments.
- PoR waveform on multiple vendor platforms
- Secure And Below (SAB) communications
Katana™
Katana™: TrellisWare’s Next-Generation Waveform
Increasing resiliency for the modern battlefield with the modernization of long-range narrowband communications
- Designed to operate in highly contested radio frequency (RF) communication environments, the Katana waveform combines resilient narrowband fast frequency hopping with tactical MANET
- Facilitates communications in near-peer threat environments and provides broad spectrum allocation options for global deployment
- Interoperable with the WREN-NB waveform at the SBU security level
